The low price is the biggest plus. Lenovo has polished the chassis of the V155 a bit and put cheap, but also game-ready hardware into the 15-inch case. The result is the IdeaPad L340 Gaming, which has a price of less than . Of course, there is no high-end gaming here. In our review, we will show exactly where compromises need to be made.

Besides the numerous office devices, Lenovo also equips IdeaPad laptops with a reasonably powerful graphics card, delivering a usable gaming laptop at a price of less than. With an Intel Core i5-9300H and Nvidia's GeForce GTX 1650, many games should be smoothly playable, but you will have to do without very high graphics settings with current blockbusters. In addition, there is 8 GB of memory and a 512 GB SSD.

Cheap gaming laptops can also be found with other manufacturers, which is why we compare the IdeaPad L340 Gaming to corresponding devices from the competition in this review. For this, we chose the Asus ROG Zephyrus G GA502DU, the Asus TUF FX505DT-EB73 and the HP Omen 15-dc1020ng. We have also included the 17-inch IdeaPad L340-17IRH, which is identically equipped. Other laptops from our database can also be added for comparison under each table.

Lenovo ideapad L340 15″ Gaming (L340-15IRH) - Specs
CPU
Intel Core i7-9750H 8 Intel Core i5-9300H 15 AMD Ryzen 5 3500U 46
GPU
NVIDIA GeForce GTX 1650 (Laptop) 32 NVIDIA GeForce GTX 1050 (3GB GDDR5) 45
Display
15.6”, Full HD (1920 x 1080), IPS
15.6”, Full HD (1920 x 1080), TN
HDD/SSD
up to 2000GB SSD + up to 1000GB HDD
RAM
up to 16GB
OS
Windows 10, Windows 10 Home, No OS
Battery
45Wh, 3-cell
Dimensions
363 x 254.6 x 23.9 mm (14.29" x 10.02" x 0.94")
Weight
2.19 kg (4.8 lbs)
Ports and connectivity
1x USB Type-C 3.0 (3.1 Gen 1)
2x USB Type-A 3.0 (3.1 Gen 1)
HDMI 2.0
Ethernet LAN
Wi-Fi 802.11ac
Bluetooth 4.2
Audio jack combo audio / microphone jack
Features
Fingerprint reader
Web camera HD 720p with physical shutter
Backlit keyboard
Microphone Digital dual-array
Speakers 2x 1.5W
Optical drive optional
Security Lock slot

What’s in the box?

Inside the package that houses the Ideapad L340 Gaming (15″), there is nothing more than some foam, paper manuals, and a 135W power adapter.

Design and construction

As we already mentioned, the Ideapad L340 Gaming (15″) has a stylish look to it. It is made entirely out of plastic, just like the Legion Y540, although, the paint is glossy and easily scratchable, in contrast to the rubberized base and the circular design on the lid of the latter. Even though it is a gaming unit, it looks almost the same as its non-Gaming brother – the Ideapad L340 (15″) – it weighs the same at 2.20 kg, while the profile of the gamer boy is slightly thicker – 23.9mm vs 22.9mm.

Opening the lid with one hand is possible only if you are using your knee to hold the base. Still, on the downside, the hinge is not stiff enough in an open position and the display shakes pretty nastily when you push the laptop by accident. Moreover, the lid itself flexes significantly, when you force it to. Despite that, we were not entirely disappointed with this one, because it has its camera on its orthodox position and it goes down for a full-flat experience of the 180-degree hinge.

Looking down to the base, we see a keyboard, that looks like is made for typing, rather than gaming. Here we got pretty much the same layout as on the regular Ideapad L340 (15″) plus an additional backlight. In terms of comfortability, the keyboard has a good key travel, decent tactile feedback, and large keycaps, which always enhances the experience when typing.

Then, there is the touchpad. To say we hated it would be an understatement. We noticed some random inputs like, it just feels it is too sensitive to touch.

On its bottom panel, two pretty large ventilation grills act as an air intake, while the exhaust hot air is going out from the area between the laptop and the display. Its speakers are placed on the two sides of the laptop, similarly to the regular Ideapad L340 (15″).

Ports

Reminiscent to what we were seeing in the past, the Ideapad L340 Gaming (15″) has all of its ports on the left side of the chassis – It starts with the dedicated Lenovo charging port, an RJ-45 connector, an HDMI 2.0 port, then two USB Type-A 3.1 (Gen. 1) ports, an audio jack and a USB Type-C 3.1 (Gen. 1) port.

You won’t be needing any special tools to get in touch with the internals of this notebook. There are 11 Phillips-head screws that you have to unscrew before you proceed.

The first thing inside we see is … the amount of free space surrounding the hardware – more on that, later.

Cooling-wise, the set up seems to be a rip off the Ideapad 330 15‘s cooling solution. In fact, it is the exact same thing, as you can see from the images below. However, this is not necessarily a bad thing, because the Ideapad 330 (15) was actually doing pretty good in terms of thermals.

At first sight, there is only one storage option available – the M.2 PCIe slot. However, if you look closely, there are four mounting points for a 2.5″ SATA drive, while the connector lies beneath the M.2 device. Additionally, there are 4GB of soldered RAM on board, as well as one RAM DIMM for upgrades.

Ideapad L340 Gaming (15″) is 45Wh – not the largest, but expected for a budget gaming laptop.

Display quality

Lenovo Ideapad L340 Gaming (15) is equipped with a Full HD TN panel with a model number BOE NT156FHM-N61 – the same one you saw on the non-Gaming version. Its diagonal is 15.6″ (39.62 cm), and the resolution 1920 х 1080 pixels. The screen ratio is 16:9, and we are looking at a pixel density of – 142 ppi, and a pitch of 0.18 х 0.18 mm. The screen turns into Retina when viewed at distance equal to or greater than 60cm (24″) (from this distance one’s eye stops differentiating the separate pixels, and it is normal for looking at a laptop).

As expected from a TN panel – the viewing angles are terrible. We offer images at 45° to evaluate image quality.

The measured maximum brightness of 227 nits in the middle of the screen and 212 nits as an average for the whole area, with a maximum deviation of 14% in the top right corner. The Correlated Color Temperature on a white screen is 7060K – colder than the optimal for the sRGB standard of 6500K.
In the illustration below you can see how the display performs from a uniformity perspective. In other words, the leakage of light from the light source.

Values of dE2000 over 4.0 should not occur, and this parameter is one of the first you should check if you intend to use the laptop for color-sensitive work. The contrast ratio is mediocre – 230:1.

To make sure we are on the same page, we would like to give you a little introduction to the sRGB color gamut and the Adobe RGB. To start, there’s the CIE 1976 Uniform Chromaticity Diagram that represents the visible specter of colors by the human eye, giving you a better perception of the color gamut coverage and the color accuracy.

Inside the black triangle, you will see the standard color gamut (sRGB) that is being used by millions of people in HDTV and on the web. As for the Adobe RGB, this is used in professional cameras, monitors, etc for printing. Basically, colors inside the black triangle are used by everyone and this is the essential part of the color quality and color accuracy of a mainstream notebook.

Still, we’ve included other color spaces like the famous DCI-P3 standard used by movie studios, as well as the digital UHD Rec.2020 standard. Rec.2020, however, is still a thing of the future and it’s difficult for today’s displays to cover that well. We’ve also included the so-called Michael Pointer gamut, or Pointer’s gamut, which represents the colors that naturally occur around us every day.

The yellow dotted line shows Lenovo Ideapad L340 Gaming (15)’s color gamut coverage.

Its display covers 50% of the sRGB/ITU-R BT.709 (web/HDTV standard) in CIE1976.

Our “Design and Gaming” profile delivers optimal color temperature (6500K) at 140 cd/m2 luminance and sRGB gamma mode.

We tested the accuracy of the display with 24 commonly used colors like light and dark human skin, blue sky, green grass, orange, etc. You can check out the results at factory condition and also, with the “Design and Gaming” profile.

Below you can compare the scores of Lenovo Ideapad L340 Gaming (15) with the default settings (left), and with the “Gaming and Web design” profile (right).

The next figure shows how well the display is able to reproduce really dark parts of an image, which is essential when watching movies or playing games in low ambient light.

The left side of the image represents the display with stock settings, while the right one is with the “Gaming and Web Design” profile activated. On the horizontal axis, you will find the grayscale and on the vertical axis – the luminance of the display. On the two graphs below you can easily check for yourself how your display handles the darkest nuances but keep in mind that this also depends on the settings of your current display, the calibration, the viewing angle, and the surrounding light conditions.

Response time (Gaming capabilities)

We test the reaction time of the pixels with the usual “black-to-white” and “white-to-black” method from 10% to 90% and vice versa.

We recorded Fall Time + Rise Time = 11 ms.

PWM (Screen flickering)

Pulse-width modulation (PWM) is an easy way to control monitor brightness. When you lower the brightness, the light intensity of the backlight is not lowered, but instead turned off and on by the electronics with a frequency indistinguishable to the human eye. In these light impulses, the light/no-light time ratio varies, while brightness remains unchanged, which is harmful to your eyes. You can read more about that in our dedicated article on PWM.

Lenovo Ideapad L340 Gaming (15) doesn’t flicker at any brightness level. This makes it comfortable for long working periods, without being harmful in this aspect.

Blue light emissions

Installing our Health-Guard profile not only eliminates PWM but also reduces the harmful Blue Light emissions while keeping the colors of the screen perceptually accurate. If you’re not familiar with the Blue light, the TL;DR version is – emissions that negatively affect your eyes, skin and your whole body. You can find more information about that in our dedicated article on Blue Light.
Conclusion

Similarly to the non-Gaming Ideapad L340 (15″), the Lenovo Ideapad L340 Gaming (15″) has a TN panel with a Full HD resolution, fast reactions time and comfortable backlight in terms of PWM. On the donwside, it has terrible viewing angles, poor contrast ratio and mediocre color coverage.

Sound

Lenovo Ideapad L340 Gaming (15)’s speakers produce a relatively loud sound with not bad quality. Additionally, its low, mid and high tones are clear of deviations.

Drivers

Now, we conduct the battery tests with Windows Better performance setting turned on, screen brightness adjusted to 120 nits and all other programs turned off except for the one we are testing the notebook with. There is a 45Wh battery pack inside this machine.

Despite the relatively small size – we got 7 hours of web browsing and around 5 hours and 45 minutes of video playback.
CPU options

You can pick one of two very respectable offerings by Intel – the quad-core Core i5-9300H or the six-core Core i7-9750H.
Lenovo ideapad L340 15" Gaming (L340-15IRH) CPU variants

Here you can see an approximate comparison between the CPUs that can be found in the Lenovo ideapad L340 15" Gaming (L340-15IRH) models on the market. This way you can decide for yourself which Lenovo ideapad L340 15" Gaming (L340-15IRH) model is the best bang for your buck.

Note: The chart shows the cheapest different CPU configurations so you should check what the other specifications of these laptops are by clicking on the laptop’s name / CPU.
GPU options

As of the graphics card of choice, there is a (watch closely) 3GB version of the GeForce GTX 1050 and one of the new Turing chips inside of a GeForce GTX 1650 with 4GB of GDDR5 memory.
Lenovo ideapad L340 15" Gaming (L340-15IRH) GPU variants

Here you can see an approximate comparison between the GPUs that can be found in the Lenovo ideapad L340 15" Gaming (L340-15IRH) models on the market. This way you can decide for yourself which Lenovo ideapad L340 15" Gaming (L340-15IRH) model is the best bang for your buck.

Note: The chart shows the cheapest different GPU configurations so you should check what the other specifications of these laptops are by clicking on the laptop’s name / GPU.
Gaming tests

Grand Theft Auto V (GTA 5)Full HD, Normal Full HD, HighFull HD, Very High
Average 88 fps 61 fps 35 fps

Far Cry 5Full HD, Normal (Full HD, High Full HD, Ultra
Average 45 fps 41 fps 39 fps

Rise of the Tomb Raider (2016)Full HD, Lowest Full HD, MediumFull HD, Very High
Average 82 fps 58 fps 27 fps

Tom Clancy’s Ghost Recon WildlandsFull HD, Medium Full HD, HighFull HD, Very High
Average 42 fps 38 fps 33 fps

Lenovo Ideapad L340 Gaming Laptop, 15.6 Inch FHD (1920 X 1080) IPS Display

Temperatures and comfort
Max CPU load

In this test we use 100% on the CPU cores, monitoring their frequencies and chip temperature. The first column shows a computer’s reaction to a short load (2-10 seconds), the second column simulates a serious task (between 15 and 30 seconds), and the third column is a good indicator of how good the laptop is for long loads such as video rendering.

Average core frequency (base frequency + X); CPU temp.

Intel Core i5-9300H (45W TDP)	0:02 – 0:10 sec	0:15 – 0:30 sec	10:00 – 15:00 min
Lenovo Ideapad L340 Gaming (15″)	2.39 GHz @ 52°C	3.72 GHz (B+55%)@ 87°C	2.92 GHz (B+22%)@ 78°C
Intel Core i5-8300H (45W TDP)	0:02 – 0:10 sec	0:15 – 0:30 sec	10:00 – 15:00 min
ASUS TUF Gaming FX505	3.25 GHz (B+41%) @ 92°C	3.13 GHz (B+36%) @ 92°C	2.98 GHz (B+30%) @ 92°C
Dell G3 17 3779	3.44 GHz (B+50%) @ 98°C	3.29 GHz (B+43%) @ 98°C	3.11 GHz (B+35%) @ 91°C

Lenovo has opted for strange management of the thermals and the frequencies of this device. First, the Core i5-9300H didn’t Turbo under pressure for a good 10-15 seconds. After that, we saw a pretty high frequency, reached by the cores, while the temperature was around 87C. Then at the end, it settled for 2.92 GHz – lower than what we saw from its competitors, however, the temperature was 78C – pretty comfortable.
Real-life gameplay

NVIDIA GeForce GTX 1050	GPU frequency/ Core temp (after 2 min)	GPU frequency/ Core temp (after 30 min)
Lenovo Ideapad L340 Gaming (15″)	1691 MHz @ 74°C	1620 MHz @ 74°C
Lenovo IdeaPad 330-15ICH	1718 MHz @ 65°C	1643 MHz @ 65°C
MSI GL63 8RC (GTX 1050)	1658 MHz @ 65°C	1645 MHz @ 69°C
Dell G3 17 3779	1683 MHz @ 77°C	1670 MHz @ 88°C

While the temperatures of the processor were managed pretty well, this of the graphics card was somewhat a downgrade from the Ideapad 330-15ICH, which as a matter of fact has exactly the same cooling solution. Despite that, the laptop maintained a pretty low fan speed, which resulted in noise that is far less intrusive than what we saw from other manufacturers.
Gaming comfort

In addition to the low fan noise, the laptop maintained reasonable temperatures on the outside as well.

Verdict

If you are looking out for a gaming laptop that won’t break your budget, the Ideapad L340 Gaming (15″) might seem like a pretty tempting choice. In fact, at first sight, the laptop looks very good and if it wasn’t for the sticker Gaming on the base of the chassis, one would never tell that this device has the ability to run some AAA titles.

Everything just seems too good to be true. Because… it is. Its low price is mainly derived from its poor build quality and TN panel. Of course, you can go for the IPS version, but then you are approaching Legion Y540 territory and the Ideapad L340 Gaming (15″) becomes less appealing. Especially with the modest GPU choice you have – a GTX 1050 with only 3GB of memory as well as a 4GB GeForce GTX 1650, which would be the natural choice, should you go for this machine.

Pairing the laptop with a budget panel was natural, given the price tag. Our configuration was equipped with a 1080p TN panel (FHD TN BOE NT156FHM-N61 (BOE0812)), that excels in terms of response times (this is important for gamers) and has no PWM in use for brightness adjustment. On the other side, the display is too dim for outdoor usage, has a horrendous contrast ratio and terrible viewing angles.

Again, doing so will set you back some more of that sweet green cash. Which means, you may probably pay just a little bit extra and get the Acer Nitro 5 or the newly updated HP Pavilion Gaming (2019), both of which have better battery life and better upgradability.

All in all, we don’t think the Ideapad L340 Gaming (15″) is really that bad of a device. It just carries too much of the older Ideapad 330 with itself and is not really focused on gaming. Should they lower the price or update some of the features of this notebook, it is going to be a perfect match for gamers on a budget.

ProsSleek design for a gaming laptop
Sufficient cooling
Backlit keyboard with large keycaps
Adequate price
Lacks PWM and has quick response times (FHD TN BOE NT156FHM-N61 (BOE0812))

Cons
Budget build quality
TN panel should be avoided
Overshadowed by its competitors
Its contrast ratio and viewing angles are dreadful (FHD TN BOE NT156FHM-N61 (BOE0812))
